IOAM Group

An IOAM Group contains an

I/O Adapter Module enclosure

and

FCDM Collection

objects, which

contain Fibre Channel disk modules (FCDMs) that are connected to this IOAM enclosure. If an
FCDM is connected to FCSAs located in different IOAM enclosures (for increased fault tolerance),
OSM displays the FCDM Collection in the lower-numbered group.

For an HP Integrity NonStop NS16000 series server, numbering of IOAM groups starts at 110.
For an HP Integrity NonStop NS14000 or NS1000 server with an IOAM enclosure, that enclosure
is located in Fabric Group 100. For other types of NonStop NS-series systems, there are no IOAM
enclosures.

For HP Integrity NonStop Bladesystems, possible IOAM groups include Groups 110-115.

Fabric Group

A Fabric Group contains:

For Integrity NonStop NS5000 or NS16000 series servers, the components that make up
both X and Y internal ServerNet fabrics, including a

processor switch

and its subcomponents.

For Integrity NonStop NS14000, NS1000, NS1200, and NS3000AC servers, the internal
ServerNet fabric objects, either an

IOAM enclosure

(at the top level) or a

VIO module

(within

each internal ServerNet fabric object), and any

FCDMs

connected to the system.

For Integrity NonStop NS2000 series, NS2100, NS2200 series, NS2300, and NS2400
series, the internal ServerNet fabric objects and a

VIO module

within each internal ServerNet

fabric object.

G16SE Group

In AC-powered Integrity NonStop BladeSystems (except for NonStop BladeSystem NB50000c),
Groups 110-115 can represent a 16-port Ethernet controller (G16SE), each of which contains two

VIO modules

(Modules 2 and 3).

Location in OSM Tree: System > Group 110-115 > VIO Module 2 and 3.

Attributes

Group

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Actions

Rediscover

Causes OSM to refresh and reanalyze the group and all subcomponents. Refresh refers to OSM
updating the attribute values displayed in the OSM Service Connection interface. Reanalyze refers
to the running of OSM incident analysis, which checks EMS event messages and creates alarms
in OSM if certain conditions exist.

Hard Disk (CLIM)

A subcomponent of the

CLIM

. For G2 and G5 CLIMs, there is only one hard disk object, located

in Bay 1. For G6 and Gen8 CLIMs, there are two hard disks, located in Bay 1 and Bay 2.

Location in OSM Tree: System > CLIMs > CLIM > Hard Disk

162

System Resources
