The state of the Expand-over-ServerNet line configured from the local node
to the selected remote node.
Values: Up, Down, Not Available Line LDEV State
The state of the Expand-over-ServerNet line configured from the remote node
to the local node.
Values: Up, Down, Unknown Remote Line LDEV State
Actions
Generate ServerNet Statistics
Generates an event containing the ServerNet statistics from the local node to the remote node.
ServerNet II Switch
The component of the 6770 switch module that provides routing for the cluster over an external
ServerNet fabric. The ServerNet II switch connects to the nodes through fiber-optic cables that
connect to plug-in cards on each node.
Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module > Switch
Example: Switch $ZZSMN.Y1
Attributes
Switch
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.
Values
Service State
Logical
A unique, read-only number stored in nonvolatile memory (SEEPROM) on a
ServerNet II switch. The Globally Unique ID can be used programmatically
to identify the switch. GUID
Whether a switch is configured for operation on the X fabric or the Y fabric.
Values: X, Y, or Clear Fabric Setting
Firmware
The version of the firmware currently loaded on the switch. The attribute value
includes the VPROC string with the firmware version in parentheses. You can
also obtain this value from SCF.
Example: T0569G06^06MAY02^FMW^AAF (3_0_82) Version
The name of the file to be used for a firmware update. Default File Name
The version of the firmware to be used for a firmware update. Default File Version
The differences, if any, between the current and default firmware versions.
Values
Compare State
