Optical Extender PICs

located only in HP Integrity NonStop NonStop NS14000 series, NS2000

series, NS2100, NS2200 series, NS2300, NS2400 series, NS1200, or NonStop NS1000
systems containing VIO enclosures.

In slot 2, an extender PIC can be used for connectivity to additional processors, with ports 1
through 4 corresponding to processors 4 through 7.

In slot 5 (Integrity NonStop NS14000 series servers only), an extender PIC can be used for
ServerNet cluster connectivity. Port 1 is where the cable from the cluster switch is physically
connected to. For more information about ServerNet cluster connectivity for VIO enclosures,
see the ServerNet Cluster Supplement for NS-Series.

ServerNet switches located in Enclosures in NonStop BladeSystems. Under these port objects,
OSM displays Fiber objects.

Attributes

Logical

Values include: QSFP, POP4, SFP, Snap12

Connector Type

Displays the status of this port.
Values: Disabled, Neighbor Check In Progress, Enabled

Link Status

Displays the status of the port to which this port is connected.
Values: OK, Fabric connection error, PIC connection error, Port connection
error, Domain connection error, System connection error, Timeout error,
Unknown

Neighbor Check Status

NOTE:

In processor switches, these attributes are not displayed for Port 1 of the crosslink PIC

located in slot 3.

Actions

None.

ServerNet Switch (Blade Enclosure)

There are two ServerNet switches in each

Enclosure

of a NonStop BladeSystem. Under each switch

object, OSM displays

Port

objects.

OSM software communicates with an internal part of the switch known as the Maintenance Entity
(ME) by a connection established through the

Maintenance Switch

.

Location in OSM Tree: System > Enclosure > ServerNet Switch

Attributes

ServerNet Switch

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Physical

The part number of the component that was assigned in manufacturing.

Part Number

The product name of the component as assigned by the manufacturer.

Product Name

ServerNet Switch (Blade Enclosure)

213
