Physical

Identifies the manufacturer of the component.

Manufacturer

The part number of the component that was assigned in manufacturing. Use part numbers
for identifying and ordering parts.

Part Number

The serial number of the component assigned to it by the supplier of the component.

Serial Number

The vendor hardware type.

Type

Physical Location

The values displayed by these attributes are assigned through the

Set Physical Location

action.

A user-defined name assigned to identify the rack in which the FCDM is
located.

Rack Name

A number (from 1 to 42) assigned to describe the location of the FCDM
within the rack.

Rack Offset

An optional text string assigned to further identify the physical location of
the FCDM.
This attribute is displayed only if a value is specified using the Set Physical
Location action.

Locator

For DC-powered Telco systems only.
Displays the system alarm panel (SAP) identifier for this hardware resource,
as specified through the Alarm Panel Identifier option within the

Set Physical

Location

action. This attribute is displayed only if a value is specied through

the action.

Alarm Panel Identifier

Logical

The product identifier of the component assigned to it by the supplier of the component.

Vendor Product ID

A code that identifies the generation of the component. Assigned by the supplier of the
component.

Vendor Product Revision

A unique, 64-bit number assigned to the hardware ports.

World Wide Name

Path B

The location of FCSA connected to the disk drive through Port B.
Example: FCSA.FSAC-1.GRP-111.MOD-2.SLOT-1

Configured Controller Location

Identifies the FCSA FSAC connected to the FCDM through Port B.
Example: FCSA FSAC (111.2.1.1)

Fibre Channel Controller

Path A

The location of FCSA connected to the disk drive through Port A.
Example: FCSA.FSAC-1.GRP-111.MOD-2.SLOT-1

Configured Controller Location

Identifies the FCSA FSAC connected to the FCDM through Port A.
Example: FCSA FSAC (111.2.1.1)

Fibre Channel Controller

FCDM

145
