Physical

A code that identifies the generation of the component. Hardware revision
codes are used for tracking components.

Hardware Revision

Indicates whether the VIO logic board LED is on or off.

LED State

Identifies the manufacturer of the component.
Displayed for VIO logic board in S-series VIO modules only.

Manufacturer

The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.

Part Number

A unique serial number that identifies the component. Track IDs are used for
tracking components.

Track ID

Logical

The date and time of the last soft reset of the VIO logic board.

Time of Last Reset

This attribute is displayed only within the Multi-Resource Actions dialog box,
to indicate whether the VIO logic board is on the X or Y fabric.

Fabric Side

ME FPGA

The VPROC of the ME FPGA (Field Programmable Gate Array) image
currently loaded on the VIO logic board.

Version

The full path name of the default ME FPGA file on the server.

Default File Name

The version of the ME FPGA image in the default FPGA file.

Default File Version

The differences, if any, between the current and default ME FPGA versions.

Values

Compare State

ME Firmware

The version of the ME firmware running on the VIO logic board.

Version

The name of the file to be used for a firmware update.

Default File Name

The version of the firmware to be used for a firmware update .

Default File Version

The differences, if any, between the current and default firmware versions.

Values

Compare State

Actions

Dump Memory

Dumps a snapshot of the VIO logic board's memory to a file in $SYSTEM.ZSERVICE.

You can view the filename in the Action Detail dialog box for this action.

The filename convention is ZMmmmssn, where:

mmm

= group number

ss

= module number

n

= version number (incremented for subsequent versions of the same ZMmmmss snapshot files)

Example: ZM100023: snapshot file taken of VIO logic board in group 100, module 02, version
number 3.

VIO Logic Board 249
