VIO G4SA

In an Integrity NonStop NS-series system containing VIO enclosures (represented in the OSM
Service Connection as

VIO modules

), OSM displays a G4SA object to represent:

In slot 6, the Ethernet ports that provide the functional equivalent of a Gigabit 4-port Ethernet
adapter.

In slot 7, an optional expansion VIO G4SA.

In a NonStop BladeSystem NB54000c and NB56000c or NonStop S-series system containing

VIO modules

), OSM displays a G4SA object to represent:

In slot 6, the Ethernet ports that constitute a V4SE, which replaces a

GESA

.

In slot 7, for S-series only, (optional) additional ports that allow you to upgrade a V4SE to a
V8SE.

Each VIO G4SA contains one

G4SA SAC

, which contains up to four

G4SA PIF

s, resulting in four

Ethernet ports on each VIO G4SA.

Location in OSM Tree: (

For NS-series: System > Fabric Group 100 > Internal ServerNet Fabric > VIO Module > G4SA.

For S-series: System > Group 11-84 > VIO Module 2 > G4SA.

For NonStop BladeSystem NB54000c and NB56000c: System > Group 110-115 > VIO
Module > G4SA.

In the Multi-Resource Actions dialog box, these G4SA objects are displayed as VIO G4SAs.

Attributes

G4SA

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Physical

A code that identifies the generation of the component. Hardware revision
codes are used for tracking components.

Hardware Revision

Identifies the manufacturer of the component.
Displayed for VIO G4SAs in S-series VIO modules only.

Manufacturer

The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.

Part Number

A unique serial number that identifies the component. Track IDs are used for
tracking components.

Track ID

Logical

The configuration type of this resource.
Values: CCSA, E4SA, FESA, G4SA, GESA, TRSA, Unknown

Configured Type

The state of the component as known to the operating system on the server.

Values

Device State

VIO G4SA 247
