IOAM names in OSM include the group number and a module number of either 2 or 3. For
example, IOAM 13.2 is located in group 13, module 2. The other IOAM in this IOAM group is
IOAM 13.3.

NOTE:

If for any reason a ServerNet switch board is not present in a module, the fans, power

supplies, and adapters in that module will not appear in OSM.

Location in OSM Tree: System > Group > IOAM Enclosure > IOAM

Example: IOAM 13.2

Attributes

Physical

A code that identifies the generation of the component. Hardware revision
codes are used for tracking components.

Hardware Revision

The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.

Part Number

A unique serial number that identifies the component. Track IDs are used for
tracking components.

Track ID

Actions

Read LCD

Displays all 16 lines of the IOAM’s LCD text in the Action Detail dialog box.

Retrieve Network Connectivity Info

Displays remote IP addresses stored in the IPAUTH file of the processor switch.

Synchronize FIR Files to Other Switches

Synchronizes the FRU information record (FIR) files of the X and Y fabric processor switches.

Write LCD Line

Allows you to edit the text displayed by the IOAM’s LCD. You can modify lines 9 through 15 with
this action.

IOAM Enclosure

An enclosure that contains two

I/O Adapter Modules

.

Location in OSM Tree: System > Group > IOAM Enclosure

Example: IOAM Enclosure 110

NOTE:

For an Integrity NonStop NS14000 or NS1000 system, there is only one IOAM enclosure.

In the OSM tree pane, it is located within the Fabric Group 100 object. In the Multi-Resource
Actions dialog box, the IOAM enclosure is displayed as an IOAM/Switch Enclosure.

Attributes

IOAM Enclosure

Displayed in the Attributes tab and Attributes dialog box only if the value is something
other than OK.

Values

Service State

166 System Resources
