Attributes

Hard Disk

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Firmware

The version of the firmware running on the CLIM hard disk.
Example: HPD5

Firmware Version

Physical

The model number of the CLIM hard disk that was assigned in manufacturing.

Model

The serial number of the CLIM hard disk.

Serial Number

Logical

The state of the CLIM hard disk as known to the operating system on the
server. Possible values include: OK, Warning, Fault, Off Duty, Not Installed.

Device State

Actions

Replace

Launches a guided procedure to make replacement of a CLIM hard disk drive more automated. If
SNMP is not available and Hard Disk object is not displayed in the OSM Service Connection, the
same guided procedure can be launched through the

Replace Hard Drive

on the

CLIM

object.

InfiniBand HCA Card (CLIM)

A subcomponent of the

CLIM

object for G6 CLIMs only.

Location in OSM Tree: System > CLIMs > CLIM > Infiniband HCA

Attributes

Infiniband HCA Card

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Logical

The state of the InfiniBand HCA card as known to the operating system on
the server. Possible values include: OK and Fault.

Device State

A text string displaying a globally unique identifier (GUID) for each InfiniBand
HCA card, as assigned by the channel adapter vendor. It is obtained through
an SNMP call. If the value is not available (for example, because the
Maintenance Interface IP address is not available or the InfiniBand SNMP
Agents are not functioning properly), it is displayed as “Not Available.”

Node GUID

InfiniBand HCA Card (CLIM) 163
