Set Locator

Allows you to enter text to aid in locating or identifying the switch. This text is displayed as the
Locator attribute. These ASCII characters cannot be used in the Set Locator field: =, +, &, or %.
Also, copy and paste features do not work in this field. For more information, see

Specifying a

Cluster Switch Locator String

.

Parameter: Locator – Free-form text up to 64 characters long.

Example: Switch On Left in 1205

SCF Equivalent: SCF ALTER SWITCH $ZZSMN, FABRIC { X | Y }, ZONE { 1 | 2 | 3 }, LAYER { 1
| 2 | 3 | 4 }, LOCATOR string

AC Transfer Switch

A component of a 6770 switch module that automatically switches to a backup AC power source
if the primary source fails.

Location in OSM tree: External ServerNet Fabric > Switch Module > AC Transfer Switch

Example: AC Transfer Switch $ZSMN.X1

Attributes

AC Transfer Switch

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Logical

The state (On or Off) of the backup power source for the switch. If both the
primary and backup sources of power fail, the UPS provides two hours of
backup power.

Backup Rail Power State

The state (On or Off) of the primary power source for the switch. If both the
primary and backup sources of power fail, the UPS provides two hours of
backup power.

Primary Rail Power State

Actions

Replace

Launches the Replace Switch Component guided procedure, which provides help for replacing the
component.

BladeCluster

The BladeCluster object is displayed at the top level of the tree pane when a NonStop BladeSystem
or NS16000 series server is a member of a

BladeCluster

. A system is added to a BladeCluster

using the

Add Node to ServerNet Cluster

action.

The BladeCluster object can be expanded in the tree pane to see

Node

objects representing the

local and all remote nodes in the BladeCluster zone.

Location in OSM tree: Located at the top level.

270 Cluster Resources
