Total Voltage Sensor

The minimum voltage that the battery should maintain is 42 volts.
If the battery's Total Voltage falls below 42 volts, an alarm is generated. (If the Total
Voltage falls below the Disconnect Voltage Limit of 39.6 volts, the battery is disconnected.)

Normal Minimum Value

The minimum voltage that the battery must maintain to continue operating is 39.6 volts.
If the battery's Total Voltage falls below 39.6, the battery is disconnected. This
disconnection could cause an enclosure or the entire system to go down.

Lower Fatal Threshold

The current combined voltage of both the upper and lower cells of the battery.
— If the Total Voltage falls below 42 volts, an alarm is generated.

— If the Total Voltage falls below the 39.6 volts, the battery is disconnected.

Current Value

The maximum voltage that the battery can hold (60 volts).

Normal Maximum Value

Actions

Enable/Disable

Prepares the battery to supply power when AC power is unavailable. The battery must be enabled
to remain charged.

Parameter: Enabled (true = enabled, false = disabled)

Blade Complex

The Blade Complex object (formerly known in OSM as the Processor Complex) contains these
NonStop NS-series processor components:

A set of one, two, or three

Blade Elements

, depending on system type and configuration.

NonStop NS14000 series and NS16000 series servers can have two or three Blade Elements
per Blade Complex, all other NS-series servers are limited to one.

Four

Logical Processors

and their

Processor Components

(which, for NonStop NS14000 series

and NS16000 series servers, includes their associated LSUs).

Attributes

Blade Complex

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

92

System Resources
