Physical

The state of the component as known to the operating system on the server.

Device State

Indicates whether or not the disk drive’s (amber) fault LED is blinking.
Value: Blinking or Off

LED State

The state of the Port A Bypass.
Possible values include: Bypass Disabled, Bypassed By Disk, Bypassed By User,
Bypassed By EMU.

Port A Bypass State

The part number of the component that was assigned in manufacturing. Use part
numbers for identifying and ordering parts.

Part Number

A unique, 64-bit number assigned to enclosure Port A.

Port A World Wide Name

The state of the Port B Bypass.
Possible values include: Bypass Disabled, Bypassed By Disk, Bypassed By User,
Bypassed By EMU.

Port B Bypass State

A unique, 64-bit number assigned to enclosure Port B.

Port B World Wide Name

The serial number of the component assigned to it by the supplier of the component.

Serial Number

A unique, 64-bit number assigned to hardware ports.

World Wide Name

Logical

The path that is currently accessing the disk.
Values: Primary, Backup, Mirror, Mirror Backup

Active Path

The current state of the backup disk path.

Values

.

Backup Path State

The logical device number used by the operating system to identify the disk.
Example: 7

Logical Device Number

The total size (in kilobytes) of disk storage space.

Media Size

The current state of the primary disk path.

Values

.

Primary Path State

A unique number that identifies the product.

Product ID

Process Pair

The state of the backup I/O process.
Values: Running, Stopped

Backup Execution State

The process ID of the backup I/O process. If the state of the backup I/O process
is Stopped, this ID is not displayed.
Example: 1,285

Backup Process ID

The two processors in which this I/O process is configured to run.
Example: 0,1

Configured Processors

The state of the primary I/O process.
Values: Running, Stopped

Primary Execution State

The process ID of the primary I/O process. If the state of the primary I/O process
is Stopped, this ID is not displayed.
Example: 1,296

Primary Process ID

Disk Pair

The name and location of the mirrored disk.
Example: Disk $DATA00-M (1.1.2).

Disk Pair Name

Disk (Fibre Channel)

121
