Neighbor ServerNet Node
The ServerNet node number of the neighbor node.
Node Number
The name of the neighbor node.
Node Name
Actions
Node Responsive Test
Tests the connectivity on the external ServerNet fabric from the local node to the remote node
connected via this port.
Switch-to-Switch PIC
A plug-in card (PIC) on the
that connects to another switch on the same fabric.
The last part of the name contains the port number where the PIC is located. Only the PICs in ports
8 through 11 of the switch are used for switch-to-switch connections.
Location in OSM tree: External ServerNet Fabric > Switch Group > Switch Module > Switch >
Switch PIC
Example: Switch PIC $ZZSMN.Y3.10 (indicates the PIC in port 10 of switch Y3)
Attributes
Switch PIC
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.
Service State
Logical
The state of connectivity between the switch and the node to which this PIC
connects.
Values:
Connected
Not Connected
Connected to Switch With Wrong Fabric
Connected to Node
Connected to Wrong Port
Connected to Different Switch
Connected to Switch With Wrong Configuration
Unknown
Connectivity Status
Whether the PIC is installed and responding.
Values: Present, Absent, Unknown
Presence
Neighbor Switch PIC
The neighbor switch and PIC to which this PIC is connected.
Example: Switch PIC $ZZSMN.X.1.8 (indicates that this PIC is connected to
switch X1, PIC 8)
PIC Name
Actions
None.
Switch-to-Switch PIC 289
