A unique serial number that identifies the component. Track IDs are used for
tracking components.

Track ID

Identifies the type of ServerNet PIC.
Value: Optical Extender PIC

Type

Logical

The state of the component as known to the operating system on the server.

Values

Device State

Actions

Power Off

Shuts off power to the Optical Extender PIC.

Power On

Restores power to the Optical Extender PIC.

Replace

Launches a service procedure describing how to replace an Optical Extender PIC.

Set LED State

Turns on or off the amber LED located on the Optical Extender PIC. The current state is indicated
by the

LED State

attribute.

PCI Riser

A subcomponent of the

CLIM

. Only one PCI Riser can be installed in G2, G5, and Gen8 CLIMs;

up to two PCI Risers can be installed in G6 CLIMs.

Location in OSM Tree: System > CLIMs > CLIM > PCI Riser

Attributes

PCI Riser

Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.

Values

Service State

Actions

Replace

Launches a documented service procedure to replace a PCI Riser in a CLIM.

PIC

A replaceable component of an

IOMF2

CRU that provides connectivity to internal ServerNet fabrics.

Location in OSM Tree: System > Group > Module > IOMF2 > PIC

Example: PIC (1.1.52.1)

PCI Riser

181
