Page 167: Set physical location

Physical Location
The values displayed by these attributes are assigned through the
action.
A user-defined name assigned to identify the rack in which the IOAM
enclosure is located. You can enter up to 15 alphanumeric characters.
Rack Name
A number (from 1 to 42) assigned to describe the location of the IOAM
enclosure within the rack.
Rack Offset
An optional text string assigned to further identify the physical location of
the IOAM enclosure.
This attribute is displayed only if a value is specified using the Set Physical
Location action.
Locator
For DC-powered Telco systems only.
Displays the system alarm panel (SAP) identifier for this hardware resource,
as specified through the Alarm Panel Identifier option within the
action. This attribute is displayed only if a value is specied through
the action.
Alarm Panel Identifier
Actions
Replace IOAM Enclosure or ServerNet Switch Board
Launches a guided procedure, which provides step-by-step instructions for replacing the entire
IOAM enclosure or an individual ServerNet switch board within the enclosure.
NOTE:
For an HP Integrity NonStop NS14000 or NS1000 system, there is only one IOAM
enclosure, requiring an IOAM enclosure replacement to be done offline. Instead of a guided
procedure, the replacement procedure for this type of system is documented in the Service Procedures
section of the NTL Support and Service library, under NonStop NS-Series Hardware Servicing.
Set Physical Location
Allows you to assign these
attributes for the IOAM enclosure:
•
Rack Name is a user-defined name for the rack containing the IOAM enclosure. You can enter
up to 15 alphanumeric characters.
•
Rack Offset is a numerical value representing the location of the IOAM enclosure within the
rack. A valid integer (from 1 to 42) must be specified when performing the Set Physical Location
action, or the action will fail.
•
Locator is an optional text string to help identify the physical location of the IOAM enclosure.
It must contain alphanumeric characters only.
•
This parameter, used for DC-powered Telco systems only, allows you to specify a system alarm
panel (SAP) identifier, which is then displayed in OSM by the Alarm Panel Identifier attribute
for this hardware resource. An system alarm panel (SAP) provides visual alarm indicators and
relays for generating three levels of alarms to alert the customer to the severity of a hardware
error in the system. By default, systems are configured with one SAP located in the CIA for
the group 11 I/O enclosure. You might need to set the Alarm Panel Identifier if the system
has multiple SAPs, you add equipment to a system, or you move equipment from one system
to another.
With T0682 H02 AAN and later, you can also use the
to set the Rack
Name and Rack Offset values in a consistent manner throughout the system while you create a
physical view of your modular racks.
IOAM Enclosure
167
