Indicates whether or not the PE is enabled for automatic reintegration in case
of a failure.

NOTE:

Displayed for NonStop NS14000 series and NS16000 series

servers only.

PE (A/B/C) Reintegration Enable State

Displayed only if a PE reintegration is in progress, this attribute displays the
progress in terms of percentage complete.

NOTE:

Displayed for NonStop NS14000 series and NS16000 series

servers only.

PE (A/B/C) Reintegration Progress

Indicates the status of the PE reintegration process. Possible values include:
No current or pending operation

Blade Element reset in progress

Blade Element reset complete

Reintegration setup in progress

Reintegration copy in progress

Reintegration copy complete

Reintegration final phase in progress

Reintegration complete

Complex invalid - no current or pending operations

Last operation failed

Operation scheduled

Settling period - no resets/reintegrations performed

Reset enabled

Reintegration enabled

Unknown

NOTE:

Displayed for NonStop NS14000 series and NS16000 series

servers only.

PE (A/B/C) Reintegration Status

The state of the PE.
Values: Running NSK, Halted State Services, Primitive, Primitive-Unable to
Join, Dead

PE (A/B/C) State

Displayed only if the PE State is something other than "Running NSK." This
attribute indicates why the PE is in its current state.

PE (A/B/C) Stop Code

The part number of the microprocessor assembly that was assigned in
manufacturing. Use part numbers for identifying and ordering parts.

NOTE:

Displayed for NonStop NS14000 series and NS16000 series

servers only.

Replacement Part Number

LSU Logic Board

NOTE:

These attributes are displayed for NonStop NS14000 series and NS16000 series servers

only.

A code that identifies the generation of the component. Hardware revision
codes are used for tracking components.

Hardware Revision

The version of the complex programmable logic device (CLPD) on the LSU
Logic Board.

LSU CPLD Version

The part number of the component that was assigned in manufacturing. Use
part numbers for identifying and ordering parts.

Part Number

Status of the LSU power supply on Rail A.

Rail A Power Status

Status of the LSU power supply on Rail B.

Rail B Power Status

200 System Resources
