$ZZCIP.C1002572.1.3 is in the slot 3 that is associated with processor 1; DIMM
$ZZCIP.C1002572.2.6 is in the slot 6 that is associated with processor 2.
•
For Gen8 CLIMs, there are 12 DIMM slots, all on a single processor.
Location in OSM Tree: System > CLIMs > CLIM > DIMM
Attributes
DIMM
Displayed in the Attributes tab and Attributes dialog box only if the value is
something other than OK.
Service State
Logical
The state of the DIMM as known to the operating system on the server.
Possible values include: OK, Degraded, Fault, Not Installed, Install Error.
Device State
Total size of the DIMM in KB.
Size
Actions
Replace
Launches a documented service procedure to replace a DIMM memory card in a CLIM.
Disk
An internal 3.5-inch hard disk drive. Each disk drive connects to one of two SCSI buses on an
CRU.
Disk CRUs can be located in slots 01 through 08 and slots 11 through 18 in I/O enclosures
(appearance side). SCSI terminators are in slots 09, 10, 19 and 20, for a total of 16 available
disk slots.
Location in OSM Tree: System > Group > Module > Disk
Example: Disk $SYSTEM-P (1.1.11)
Attributes
Disk
Displayed in the Attributes tab and Attributes dialog box only if the value is something
other than OK.
Service State
Physical
A code that identifies the generation of the component. Hardware revision codes are
used for tracking components.
Hardware Revision
Identifies the manufacturer of the component.
Manufacturer
The part number of the component that was assigned in manufacturing. Use part numbers
for identifying and ordering parts.
Part Number
Indication of whether the component is powered on.
Power State
A unique serial number that identifies the component. Track IDs are used for tracking
components.
Track ID
