Actions
Group Connectivity ServerNet Path Test
You can perform this action on either the Internal ServerNet X Fabric or the Internal ServerNet Y
Fabric. The action tests the links between SPs and ServerNet Switch Board maintenance entities
(MEs) that provide ServerNet communication between groups on the system.
Processor-to-Processor Connectivity Test
Equivalent to the SCF STATUS SERVERNET command, this action tests the ServerNet connectivity
between specified processor on this Internal Fabric. You can specify one or all processors. The
action will report any ServerNet errors between the specified processor(s) and all other processors
in the system.
Start ServerNet
Starts all ServerNet traffic through all or specified processors on the fabric.
Stop ServerNet
Stops all ServerNet traffic through all or specified processors on the fabric.
IO Module
A subcomponent of a SAS Disk Enclosure .
Location in OSM Tree: System > SAS Disk Enclosures > SAS Disk Enclosure > IO Module
Attributes
None.
Actions
Replace
Launches a documented service procedure to replace an IO module in a SAS disk enclosure.
IOAM (I/O Adapter Module)
A modular I/O adapter module, compatible with both NonStop S-series and Integrity NonStop
NS-series systems. There are two IOAMs in each
IOAM Enclosure .
Each IOAM contains:
• A ServerNet Switch Board
• Two IOAM Power Supplies
• Two IOAM Fans
• Up to five FCSA or G4SAs
• In an HP Integrity NonStop NS14000 or NS1000 system, slots 1 and sometimes 2 of each
IOAM are occupied by a
4PSE instead of an FCSA or G4SA.
NOTE: For an Integrity NonStop NS14000 or NS1000 system, an IOAM is displayed in the
Multi-Resource Actions dialog box as an IO/Switch Module.
IOAMs are initially configured using the Configure Module action in the OSM Low-Level Link, as
described in the NonStop NS-Series Hardware Installation Manual (available in the Hardware
Service and Maintenance collection of NTL).
IO Module 165
