Configuring the DAQLOGGER
The “Update Mode” dialog box opens.
Select either of the following and click “OK.” “Scan Interval” is default.
Scan Interval
Updates data of individual items at the scan interval set in the logging software.
However, the data are updated only during the scanning operation.
Record Interval
Updates data of individual items at the record interval set in the logging software.
The time and data that are displayed are the ones that are actually recorded.
However, the data are updated only during the recording operation.
The intervals mentioned above are set in the “Logger Configuration” dialog box.
For details on how to set these intervals, see section 2.9, “Configuring the Logger.”
Pausing/Terminating the DDE Server
Procedure
1. To pause or resume the DDE Server, perform the following procedure.
In the menu bar of the “DAQLOGGER DDE” window, select “DDE Server” and then
“Pause.” The updating of the topic data that are displayed in the “DAQLOGGER
DDE” window is paused. The data updating on the DDE client side is also paused.
To resume the DDE Server, select “DDE Server” and then “Resume” in the menu bar
of the “DAQLOGGER DDE” window.
2. To terminate the DDE Server, perform the following procedure.
From the menu bar of the “DAQLOGGER DDE” window, select “DDE Server” and
then “Exit” or click the “Close” button at the upper right corner of the window. The
“DAQLOGGER DDE” window closes and the data updating on the DDE client side is
stopped.
Note
If the DDE server is terminated directly, the message, “M4132 OK to stop server?” appears. If
you select Yes and a client is connected, communication is disconnected. Note that the DDE
server will not start the next time DAQLOGGER Manager is started.
2.11 Setting Up the DDE Server
