7-78 IM WX101-01E
Entering Basic Settings
Environment
Basic Environment
• Data Kind
Settings Description
Display Records display data.
E+D Records display data and event data. You cannot select [E+D] when [Trend
Rate Switching] under [Environment] - [Detail Setting] under the [Basic
setting] tab is set to [ON]. You cannot select [E+D] if you are using the multi
batch function (/BT2 option; release number 3 or later). You can set the multi
batch function by setting [Batch operation qty] under [Environment] - [Detail
Setting] in the [Basic setting] tab. You cannot select [E+D] on DXs with the
/AS1 advanced security option.
Event Records event data.
• Temperature Unit
Select C or F.
• Time zone
Set the time zone of the region in which the DX will be used in terms of the time
difference from GMT. A negative value indicates that the local time is behind the GMT.
• Time deviation limit
Time deviation limit
Current time Specified time
When
the time deviation between the time on the DX and the specified time is within
±(the value specified here), the time on the DX is gradually corrected. Otherwise, the
clock is corrected immediately.
Select from 10 s to 5 min. Select [OFF] to disables the function.
Example: If [Time deviation limit] is set to 10s and the time on the DX is 10 hours 21 minutes
15 seconds, the time on the DX is gradually corrected if the specified time is between
10 hours 21 minutes 5 seconds and 10 hours 21 minutes 25 seconds.
7.7 Setting DX1000/DX2000
