7-116
IM WX101-01E
Changing DX1000/DX2000 system configuration
If necessary, change the system configuration such as the presence or absence of
options to match the DX1000/DX2000 that is to be configured.
Changing the system configuration initializes the settings of the SET mode and SETUP
mode. Perform changes in the system configuration first.
The changes in options are reflected in the “Recorder List” window.
Procedure
1. Open the setting window of the DX1000/DX2000 of which the system configuration
is to be changed, and select “System Configuration” from the “System” menu of the
“DAQLOGGER Hardware Configurator” window. The “System Configuration” dialog
box opens.
2. Set the model, options, etc. to match the DX1000/DX2000.
3. When you finish setting the parameters, click “OK.” The setup parameters are
applied to the setup items in the tab panel.
7.7 Setting DX1000/DX2000
