6-4
IM WX101-01E
Select Group dialog box
Click the desired group to close the dialog box and apply the selected group.
Select Tag dialog box
Click the desired tag to close the dialog box and apply the selected tag.
• When set to Time
The condition is met when the time of the data being scanned exceeds the specified
time.
The condition is determined only when scanning is in progress.
Select a time interval of Minutely, Hourly, Daily, Weekly, Monthly, and Interval.
The reference day is 0. The reference day and day of week are not saved.
The setting can only be entered when Interval is specified
for Time By. The condition is “true” from 00:00 up to the
interval setting.
Selectable only when Time By is set to
Hourly, Weekly, or Monthly.
Selectable only when Time By is set to Monthly.
Selectable only when Time By is set to Weekly.
6.1 Setting Events
