7-27
IM WX101-01E
1
2
3
4
5
6
7
8
9
Index
Setting the Recorder
Setting One Computation Channel at a Time
2. The channel setting
dialog box opens.
1. Double-click the channel
you wish to set.
3. Select the tab of the item to be configured.
Click here to enter
the operator
4. After setting the items,
click here.
Set the maximum value.
Set the minimum value.
Copy the first setting.
Operator button
Select the operator type and click the operator button
The items in the math channel tab can be configured for each channel. The items that
are configured are the same as those configured on the spreadsheet. For details, see
the page corresponding to the item.
Copying and Pasting Setup Data
See page 7-24.
7.6 Setting DX100, DX200, MV100, MV200
