7-82 IM WX101-01E
• Scale over
Settings Description
Free The value is set to –over range if the value is less than –30000 and +over
range if the value is greater than 30000 excluding the decimal point. The value
is displayed as –Over and +Over, respectively.
Over The value is set to –over range if the value is less than –5% of the scale and
+over range if the value is greater than 105%. The value is displayed as –Over
and +Over, respectively.
Example: If the scale is 0.0 to 200.0, the value is set to –over range if the value is less than
–10.0 of the scale and +over range if the value is greater than 210.0.
Note
For computations such as TLOG, CLOG, and report, the handling of the scale over-range value
can be set in advance.
• Key Security
Settings Description
Login Enables only registered users to operate the DX using keys. The [User
registration] is displayed in the [Basic Setting] tab. The Key Security setting is
fixed at [Login] on DXs with the /AS1 advanced security option.
Keylock Enables the key lock function. Set the key lock function in the [Basic Setting] tab.
This option cannot be selected on DXs with the /AS1 advanced security option.
OFF Disables the security functions. This option cannot be selected on DXs with the
/AS1 advanced security option.
• Comm. Security
Settings Description
Login Enables only registered users to operate the DX via communications. The [User
registration] is displayed in the basic setting mode menu.
OFF Disables the security functions.
• Multi Login (Only on DXs with the /AS1 advanced security option)
Setting Description
On The multi-login function is used. At the same time, one user can log in through
key operations, one through an Ethernet connection (connection to the setting
function), and one through serial communication.
Off The multi-login function is not used. Users cannot log in simultaneously
through key operations, Ethernet (connection to the setting function), or serial
communication (LL command).
• Password Management (Only on DXs with the /AS1 advanced security
option)
To perform password management using a KDC server on the Ethernet, select [On].
You will have to set the [Ethernet communication] - [Password management] item.
• Auto Save
Settings Description
ON Automatically saves the measured data to the CF card.
OFF Does not automatically save the data. Save the measured data manually to
the CF card or USB flash memory (/USB1 option).
• Media FIFO
You can select this with DX main unit firmware version 2.0x or later.
This is valid only when [Auto Save] is [ON].
Settings Description
ON If there is no more free space on the CF card, the oldest file is deleted, and
the newest file is saved.
OFF If there is no more free space on the CF card, the measured data is not saved
to the CF card.
7.7 Setting DX1000/DX2000
