Printing
Procedure
1. Click the “Print” button on the toolbar or select “File” from the menu bar then select “Print.”
2. Specify the print range and other items.
Set the “Range” and “Color” of the graph viewer by clicking the radio buttons. Also
type a title if desired.
Set the “Range” of the sheet viewer or the report data.
To thin the printout, specify the number of data to advance to before the next print
(Print Step). For example, a print step of 1 prints all data, and a print step of 2 prints
every other data.
3. Click the “OK” button.
The “Print” dialog box appears.
4. Set the “Name” of the printer and “Number of copies,” then click “OK.”
Printing starts.
Note
The “Print range” in the “Print” dialog box is invalid. The “Range” specified in the “Printout
Setup” dialog box is used.
4.9 Printing Data
