7-60 IM WX101-01E
Channel Configuration
• Use
Select [ON] for the display groups that you want to display. The number of groups is
as follows
Model Multi Batch Function (/BT2 option)
Disabled or not installed
Enabled
DX1000 10 6/batch
DX2000 36 12/batch
• Group name
Set the group name. (up to 16 characters)
• Channel Configuration
Set up to 10 channels (DX2000) or 6 channels (DX1000) from measurement channels,
computation channels (/M1 and /PM1 options), and external input channels (/MC1
option, DX2000).
Note
• The trend, digital, and bar graph displays are shown in the specified order.
• A channel can be assigned to multiple groups.
• The same channel cannot be assigned multiple times in a group.
Trip line
Set lines at specified positions in the waveform display range on the Trend display.
• Use
Turn [ON] the trip lines you want to display.
• Position
Set the position in the range of 0 to 100% of the display width.
• Color
The default colors are red, green, blue, and yellow. If you want to change the color,
select from the 24 available colors.
• Trend Line
Set the line width of the trip line in dots (1 to 3).
7.7 Setting DX1000/DX2000
