7-66 IM WX101-01E
Comment (Release number 3 or later)
Click a number to open a comment
text details dialog box
Change the values in the [Comment
txt field no] boxes to display the
registered character strings
Set the Comment text field numbers
for all lines, and click OK
Comment text fields
• Number and Text info
You can register text strings to Text info boxes.
Text string: You can enter up to 32 characters.
Model Number of comment text fields
DX1000 100
DX2000 200
Comment text block
• Number and Line
You can register text strings to Comment text blocks. Register comments to comment
text blocks by combining up to 5 comment text fields. Set the comment text fields that
you want to register in the Line boxes.
Model Number of comment text blocks
DX1000 50
DX2000 100
7.7 Setting DX1000/DX2000
