7-250 IM WX101-01E
Copying and Pasting Setup Data
You can copy the setup data of one channel or more to other channels. Use the following
procedure to copy and paste.
1. Click the source channel number that you want to copy. To select many channels,
click the first source channel, then drag over all the channels that you want to copy.
2. Click the [Copy] button at the bottom of the window.
3. Click the destination channel number. To select many channels, click the first
destination channel, then drag over all the channels where you want to paste.
4. Click the [Paste] button at the bottom of the window.
You can also copy and paste specific channel items.
After selecting the copy source in step 1, click the [Copy Details] button to display the
[Meas Channel Copy Details] dialog box.
Select the items that you want to copy.
Setting One Channel at a Time
2. Click the tab of the item
to be set.
3. After setting the
items, click here.
1. Double-click the channel
to set to open the Channel
Settings dialog box
Applies the settings.
Update according to the changes
in the [Meas] sheet.
The items of the [Meas] tab can be set for each channel. The items set here are the
same as the ones in the [Meas] tab of the Hardware Configurator. For details, see the
page corresponding to the item.
7.10 Setting CX Series
