2-2 IM WX101-01E
2.2 Preparing the Recorder
Before starting DAQLOGGER, set recorder’s communication parameters then connect
the recorder to the PC.
For µR1000/µR1800/VR100/VR200
Settings for RS-422 communication
Provide the following settings.
• Baud rate: 9600 bps
• Data length: 8 bits
• Parity: None
• Stop bit: 1 bit
• Address: Set a unique address to each recorder.
See the Communication Function Manual of the recorder (IM 4D5B1-10E, IM 4H3B1-
10E, or IM 4N1A1-11E).
For DX100/DX200/DX200C/MV100/MV200/MV1000/MV2000/CX1000/CX2000/
DX1000/DX2000/DARWIN
Settings for Ethernet communication
For a model capable of Ethernet communication, set the following items.
• IP address
• Subnet mask
• Default gateway
Settings for RS-232 communication
For a model capable of RS-232 communication, provide the following settings.
• Baud rate: 38400 bps
• Data length: 8 bits
• Parity: None
• Handshake: CR:RS
• Protocol: Normal (for DX/MV/CX)
• Stop bit: 1 bit (fixed to 1 bit on DX/MV/CX)
Settings for RS-422/RS-485 communication
For a model capable of RS-422A/485 communication, provide the following settings.
• Baud rate: 38400 bps
(9600 bps when connecting µR and VR recorders on a single multidrop line.)
• Data length: 8 bits
• Parity: None
• Address: Set a unique address to each recorder.
• Protocol: Normal (for DX/MV/CX)
• Stop bit: 1 bit (fixed to 1 bit on DX/MV/CX)
For more details about communication settings, see the Communication Function Manual
for the recorder (IM 04L02A01-17E, IM MV100-17E, IM DA100-11E, IM DR231-11E, IM
DC100-11E, IM 04L31A01-17E, IM 04L41B01-17E, or IM MV1000-17E).
