7-12 IM WX101-01E
• Trip Level
Set the
trip point. This figure shows the “Trip Level” setting dialog box for VR200 S2.
Click to open the
“Select Color”
dialog box
(for VR200 S2
only)
• Waveform Span Rate
This is the rate at which the displayed waveform is updated.
For VR200 S2
only
• Message (for VR200 S2 only)
Copy and paste
messages
Sets whether or not to display the menu
that executes the message display on
the setup menu of the operation mode.
Up to 16
characters
7.4 Setting VR Series
