7-122 IM WX101-01E
7.8 Setting MV1000/MV2000
Memory Sampling
Turn [ON] (sample) or [OFF] (do not sample).
Display Zone (Zone L and U)
You can select the range of the screen in which the waveform of each channel is to be
displayed.
Specify positions (%) on the display scale for the upper and lower limits.
The conditions for setting the zones are as follows:
• Range: 0% to 100%
The lower limit L must be less than the upper limit
• The difference between the lower and upper limits is at least 5%.
Graph
For details, see section 5.7 in the MV1000/MV2000 User’s Manual (IM MV1000-01E).
Scale display position
Select the scale display position on the trend display from 1 to 10 for the MV2000 or from
1 to 6 for the MV1000. Select [OFF] if you do not wish to display the scale.
Scale divide position
Select the number of main scale marks on the trend display from 4 to 12 and C10.
C10: The scale is equally divided into 10 sections by main scale marks, and scale
values are indicated at 0, 30, 50, 70, and 100% positions on the trend display.
Bar display position
Select [Normal], [Center], [Lower], or [Upper].
Bar divide number
Select number of divisions of the scale on the bar graph display.
Partial (Partial Expanded Display)
Bound position (%)
Set the boundary for the partial expanded display. The range is from 1 to 99%.
Boundary
Set the value that is to be the boundary between the reduced section and the expanded
section in the range of “minimum span value + 1 digit to maximum span value – 1 digit.”
For channels that are set to scaling, the selectable range is “minimum scale value + 1
digit to maximum scale value – 1 digit.”
Example: Input range: –6 V to 6V. Bound position: 30. Boundary: 0
The –6 V to 0 V range is displayed in the 0% to 30% range, and the 0 V to 6
V range is displayed in the 30% to 100% range.
The conditions used to set the boundary vary depending on the measurement and
computation channels as follows:
• Measurement channel
When SCALE and SQRT are not used: Span L < boundary < span U
When SCALE and SQRT are used: Scale L < boundary < scale U
• Computation channel
Span L < boundary < span U
Note
For the MV1000/MV2000, this is when [Partial] is turned [ON] under [Detail Setting] in the [Basic
Setting] tab.
