Alarm Mark
Displays marks indicating the values of the high and low limit alarms, delay high and low
limit alarms, and difference high and low limit alarms. This setting is common with the
bar graph display.
Mark kind
Settings
Description
Alarm
Indicates green under normal conditions and red when an alarm is activated.
Fixed
Displays a fixed color.
Scale display
To display alarm point marks, select [ON].
Mark color
If the [Mark kind] is set to [Fixed], specify the color of the alarm point marks. Click a setup
box to open its display color selection dialog box. If you select [AUTO], alarm point marks
are displayed using the specified alarm display colors (by accessing [Basic setting] >
[Alarm] > [Alarm display]; release number 3 or later).
7.7 Setting DX1000/DX2000
