Setting the Recorder
Changing DARWIN system configuration
If necessary, change the system configuration such as the presence or absence of
options to match the DARWIN that is to be configured.
Changing the system configuration initializes the settings of the SET mode and SETUP
mode. Perform changes in the system configuration first.
The changes in options are reflected in the “Recorder List” window.
Procedure
1. Open the setting window of the DARWIN of which the system configuration is to
be changed, and select “System Configuration” from the “System” menu of the
“DAQLOGGER Hardware Configurator” window. The “System Configuration” dialog
box opens.
2. Set the style number, memory capacity, and options to match the DARWIN.
3. When you finish setting the parameters, click “OK.” The setup parameters are
applied to the setup items in the tab panel.
7.9 Setting DARWIN
