7-264 IM WX101-01E
7.11 Writing Setting Parameters to the Recorder
When you have finished setting the recorder, write the setting parameters back to the
recorder.
Procedure
1. In the “DAQLOGGER Hardware Configurator” window, select “Communication” then
“Send.”
The “Select Recorders” dialog box appears.
2. Select the recorders to send data to and then click the “Send” button.
• To select all the recorders Click “Select All.”
• To select individual recorders In the list, currently connected recorders are shown
in blue. Click the recorder you wish to send data and it turns red. You can select
more than one recorder.
When the destination recorder to send the settings is set to VR, DX, MV, or CX the
following message is displayed at the time when setup parameters are sent to the
VR, DX, MV, or CX.*
Select “Yes” to transmit the setup parameter to the VR, DX, MV, CX. When multiple
VRs or DXs, or MVs , or CXs are selected, the following message is displayed when
the setup parameters are sent to the next VR, DX, MV, or CX.
Select “Select All” to send the setup parameters to all selected recorders (VR, DX,
MV, or CX included).
Select “No” to skip sending the data to the particular VR, DX, MV, or CX and go to the next
recorder. When multiple VRs, DXs, MVs, or CXs are selected, the following message is
displayed when the setup parameters are sent to the next VR, DX, MV, or CX.
Select “Cancel” to cancel the transmission of the setup parameters to subsequent
recorders including the current VR, DX, MV, or CX.
* For VR recorders, the data memory may be initialized depending on the setup parameters
that are changed. For details, see the User’s Manual for the VR recorder (IM 4N1A1-01E or
IM 4N2A1-01E).
For DX/MV/CX, the data memory is initialized when the temperature unit is changed.
For DX(excluding the DX1000/DX2000)/MV(excluding the MV1000/MV2000)/CX, the
data memory is initialized when the writing method to the internal memory is changed.
For details, see the User’s Manual for the DX/MV/CX recorder (IM 04L01A01-01E or IM
04L02A01-01E, IM MV100-01E, IM MV200-01E, IM 04L31A01-01E, IM 04L31A01-03E).
