Setting the Recorder
Bar Graph Direction
Select Bar graph direction.
Brightness
Select a value from 1 to 6 (2 by default). Larger the value, brighter the display becomes.
Backlight Save Mode
Settings Description
Off Disables the backlight saver.
Dimmer Dims the display if there is no operation for a given time.
Timeoff Turns the backlight OFF if there is no operation for a given time.
Backlight Saver Time
Select a value from 1 min to 1 h. If the specified time elapses without any key operation
or alarm occurrence, the LCD backlight switches to the specified mode.
Backlight Restore
Settings Description
Key The backlight returns to the original brightness when a key is pressed.
Key&Alarm The backlight returns to the original brightness when a key is pressed or
when an alarm occurs.
Trend Background
Set the background color of the operation screen to White (default setting) or Black.
Historical Trend Background
Select the background color of the historical trend display from the following:
Settings: White, Black (default setting), Cream, and Lightgray
Scroll Time
Set the switching interval from the available settings between 5 s and 1 min. The groups
switch in ascending order.
Jump Default Display
Returns to a preset display if there is no key operation for a specific time.
Settings Description
1min to 1h Time until switching the display.
Off Disables the function.
FAVORITE Key action (Release number 3 or later)
• Action
Settings Description
History The historical trend of the currently displayed data appears when you press
the favorite key.
Favorite The displays that have been registered to the favorite key appear when you
press the favorite key. Select Favorite when you want to register displays to
the favorite key and use the key to switch between the displays.
• Group display
This setting is valid when [Action] is set to [Favorite].
Settings Description
Current Of the displays that have been registered to the favorite key, those that
display groups (the trend, digital, bar graph, and historical trend displays) are
displayed using the currently displayed group.
Saved Registered displays are displayed using the display groups that were selected
when they were registered.
• Time axis zoom
This setting is valid when [Action] is set to [Favorite].
Settings Description
Current Historical trend displays that have been registered to the favorite key are
displayed using the current time axis zoom.
Saved Historical trends are displayed using the time axis zooms that they were
registered with.
7.7 Setting DX1000/DX2000
