8-10
IM WX101-01E
Numeric Monitor
For details on general display settings, see “Setting the Display Conditions” in this
section (page 8-13).
Group alarm condition
Select the
displayed group
Turn ON/OFF the alarm indication
Switch tag number/tag name
Alarm indication (from the left: level 1, 2, 3, and 4)
Waveform
display color
Tag number/tag name
Bar display of the retrieved data
Meter Monitor
For details on general display settings, see “Setting the Display Conditions” in this
section (page 8-13).
Select the displayed group
Turn ON/OFF the link
Turn ON/OFF the alarm indication
Switch tag number/tag name
Alarm indication (from the left: level 1, 2, 3, and 4)
Tag number
/tag name
Alarm point
Group alarm
condition
Numerical display
of the current value
Bar meter Analog meter Thermometer
8.2 Monitoring the Data
