7-74 IM WX101-01E
Structure
Sets the structure of the file name when saving data.
Settings Description
Date Serial number + user-assigned character string + date
Serial Serial number + user-assigned character string
Batch Serial number + batch name (when using the batch function)
File name
Set the user-assigned section of the file name. (Up to 16 characters)
Symbols that can be used: #, %, (, ), +, -, ., @, °, and _.
Field Title, Field Characters
Set text strings. When the multi batch function (/BT2 option; release number 3 or later) is
enabled, select the appropriate batch tab.
Title: Up to 20 characters. Characters: Up to 30 characters.
The number of fields that you can use is 24 for release number 3 or later and 8 for
release number 2 or earlier.
7.7 Setting DX1000/DX2000
