Yokogawa DAQWORX - Manual (Page 184)

7-8 IM WX101-01E
• µR, VR, DX, MV, CX
Proceed to step 2.
2. Press the “Copy Details” button.
The “Copy Details” dialog box opens. The setting items contained in this dialog box
differ for each series of recorders.
3. After selecting the items to be copied, click “OK.”
4. Select the “CH” cell of the channel to copy to (you can select more than one
channel).
To select channels over a series of numbers, click the first cell then, pressing the
SHIFT key, click the last cell.
5. When you have finished selecting, press the “Paste” button.
Note
You cannot copy between a measurement channel and a computation channel.
7.3 Editing the Setting Parameters
