Error and System Messages
Section 16
16-38
Message Description
ROTARY WORD OUT OF RANGE A rotary axis was programmed to move to an absolute position that is greater than or equal to
360 degrees. In absolute mode, a rotary word must range between 0 and 360 degrees.
ROUGHING CYCLE NESTING ERROR The contour blocks called by a roughing cycle to define the finished contour of a part contain a
block that likewise calls for a roughing cycle. Contour blocks for a roughing cycle cannot contain
a block that likewise calls for a roughing cycle.
ROUGHING CYCLE PROGRAMMING ERROR A syntax error has been found in a roughing routine block (G72, G73, G74, or G75).
RUNG NUMBER NOT FOUND The rung number you are searching for in the search monitor utility does not exist in the current
module, or does not exist in the program in the direction you are searching.
S
S--CURVE ACC/DEC CONFIGURATION ERROR An axis configuration error was detected by the control when the programmed acc/dec ramp
was out of range. An attempt to program an acceleration ramp value of 0 in a G48.3 or G48.4
block. An attempt was made to program another G--code in a block with a G48.x.
S--CURVE MIN PROG JERK TOO SMALL An attempt was made to select a jerk value below the allowable AMPed value.
S--CURVE MODE NOT ALLOWED This message displays when an attempt was made to use a feature that is illegal in S--Curve
Acc/Dec mode. The following can not be used with S--Curve Acc/Dec: 7300 Series Tape
Compatibility, PAL Axis Mover, Circular Interpolation Mode (G02, G03), Feed to Hard Stop
(G24), jogging, threading, and solid tapping.
S--CURVE OPTION NOT INSTALLED An attempt was made to select S--Curve Acc/Dec (G47.1) when the S--Curve option bit was set
to false. Make sure your system includes the S--Curve option.
S NOT LEGAL PROGRAMMING AXIS NAME This is displayed at power-up when the letter “S”is assigned to linear or rotary axis. Only the
spindle(s) can be AMPed with “S”as the name; it cannot be assigned to a programmable axis.
S OVER SPEED A servo motor is turning at an RPM that is greater than the maximum RPM allowed for that
servo as defined in AMP by the system installer. For digital spindles this error can result from
maximum RPM gear range 1 being set higher than your AMPed allowed Maximum Motor
Speed.
SAVE COMPLETED The changes made to the current device set-up have been saved.
SCALE FACTORS MUST BE EQUAL FOR PLANE When performing circular motion or motion in certain cycles, keep the scale factors for the axes
of the active plane equal.
SCALING INVALID DURING POLAR Scaling cannot be used during polar programming.
SEARCH ALREADY IN PROGRESS You cannot request a search operation while one is currently running. Complete or abort the
current search before attempting another search.
SEARCH MONITOR SELECT NOT ALLOWED You can not use the online PAL search monitor utility while the display select function softkeys
are active. Leave the display select screens (press DISP SELECT) before you try to access the
search monitor utility.
SEARCH REQUIRES AN ACTIVE PROGRAM An attempt has been made to perform a search operation when no program was selected for
execution. A program must be selected for automatic execution before a program search can
be performed.
SEARCH STRING NOT FOUND The character or character string designated in the search operation was not found.
SECOND SPINDLE NOT CONFIGURED For spindle 2 to be programmable, it must be configured in AMP; a decode error.
SECONDARY AUX. WORD SAME AS AXIS NAME The secondary auxiliary word (usually B) is the same as an axis name, causing an interpretation
conflict for the control. This word and all axis names are assigned in AMP.
SEE (MESSAGE) IN PROGRAM BLOCK The programmer has assigned a system parameter that generates this message, telling the
operator to read the comment in the current part program block. Program execution will resume
when cycle start is pressed.
SEQUENCE NUMBER OUT OF RANGE A sequence number beyond the range of 1 - 99999 was programmed.
