Section 2A
Planning Your System Layout
2A-2
Table 2A.A
Environmental Conditions
Condition
Range or Limit
Operating temperature
CPU Board and Servo Amplifiers:
0
°
C to 55
°
C (32
°
F to 131
°
F) except 9/440
0
°
C to 50
°
C (32
°
F to 122
°
F) 9/440 only
Operator Panels (standard and removable):
0
°
C to 55
°
C (32
°
F to 131
°
F)
0
°
C to 45
°
C (32
°
F to 113
°
F) external ambient
Operator Panels (flat):
0
°
C to 50
°
C (32
°
F to 122
°
F)
0
°
C to 40
°
C (32
°
F to 104
°
F) external ambient
Operator Panels (pendant):
0
°
C to 55
°
C (32
°
F to 131
°
F)
0
°
C to 40
°
C (32
°
F to 104
°
F) external ambient
8500 Digital Servo Motors:
0
°
C to 40
°
C (32
°
F to 104
°
F)
Storage or Transport Temperature
CPU Board, Servo Motors, and Servo Amplifiers
-30
°
C to 70
°
C (-40
°
F to 158
°
F)
Operator Panel:
-30
°
C to 65
°
C (-40
°
F to 131
°
F)
Maximum Temperature Change Rate
1.1
°
C/min. (1.80
°
F/min.)
Altitude
Above temperature based on operation at 1000m (3500 ft)
Atmosphere
Components placed in a protected enclosure with filtered
air. Avoid placing components in areas where there is high
concentration of dust, cutting oil, or organic solvents.
Relative Humidity
CPU Board and Operator Panel
5-95% (no condensation)
8500 Digital Servo Motors
20-80% (no condensation)
Vibrations (operating)
Max. 1.0 G (operator panel)
Max. 2.5 G (all 9/Series controls except 9/440)
Max. 1.0 G (9/440 CNC)
Max. 2.5 G (E-150 Series I/O)
ATTENTION: Environmental conditions exceeding those
shown above may cause component failure and/or unpredictable
control operation.
