Rockwell Automation 8520 9/Series CNC Integration Maintenance Manual Documentation Set User Manual
Page 66

Section 2B
Mounting Dimensions
2B-9
Figure 2B.9
9/440 CNC and 1394 Drive Dimensions
for AM50 and AM75 Axis Modules
350.0
(13.78)
400.0
(15.75)
37.5
(1.48)
75.0
(2.95)
75.0
(2.95)
Dimensions are in millimeters and (inches)
All slots accept M6, 1/4--20 mtg. screws
Mounting Hole Detail
12.0 (0.47)
385.0 (fastener location)*
(15.16)
8.0 (0.31)
8.0 (0.31)
10.1 (0.40)
15.9 (0.63)
8.0 (0.32)
When using the gasket provided with the axis module,
torque the M6 to 7.9 N--m and the 1/4--20 to 75 in--lbs.
75.0
(2.95)
75.0
(2.95)
*Note: Dimension shown is for mounting hardware
location and does not reflect the location
of the lower slot radius.
*Note: Heat sink width only.
Remove the paper backing
and attach the gasket here
(hole side on top)
