Section 10B
9/Series Adapter Modules for
1771 and 1746 I/O Devices
10B-9
Catalog Number: Description:
1746--OV16 24V dc 16 Output Module (sink)
1746--OV32 24V dc 32 Output Module (sink)
V ac/V dc Relay Output Modules
1746--OW4 V ac/V dc Relay 4 Output Module
1746--OW8 V ac/V dc Relay 8 Output Module
1746--OW16 V ac/V dc Relay 16 Output Module
1746--IO4 120V ac 2 Inputs & ac/dc Relay 2 Outputs
1746--IO8 120V ac 4 Inputs & ac/dc Relay 4 Outputs
1746--IO12 120V ac 6 Inputs & ac/dc Relay 6 Outputs
Analog I/O Modules
1746--NI4 Analog 4 Input Module (--20ma to +20ma) or (--10V dc to +10V dc)
1746--NIO4I Analog 2 Inputs (--20ma to +20ma) or (--10V dc to +10V dc) & 2 Outputs (0 to 20ma)
1746--NIO4V Analog 2 Inputs (--20ma to +20ma) or (--10V dc to +10V dc) & 2 Outputs
(--10V dc to + 10V dc)
1746--NO4I Analog 4 Output Module (0 to 20ma)
1746--NO4V Analog 4 Output Module (--10V dc to +10V dc)
Specialty I/O Modules
1746--IG16 5V dc/TTL 16 Input Module (source)
1746--OG16 5V dc/TTL 16 Output Module (sink)
1746--OBP16 24V dc 16 Output Module (enhanced source)
1746--IN16 24V ac/V dc 16 Input Module (source)
1746--OX8 ac/dc Isolated Relay 8 Output Module
Important: To configure a 12--bit I/O module using the I/O assignments
application, you must select a 16--bit device, while only assigning the first
12 I/O points.
