Section
12
12-1
Wiring A-B Analog Drives
This section discusses the wiring of Allen-Bradley Analog servo drive
amplifiers. This manual is not intended to be used in place of
documentation that accompanies an A-B drive but should be used with
such documentation. The following table lists the Allen-Bradley drives
supported by the control that are covered in this section.
Table 12.A
A-B Drives Selection Guide References
A- B Drive
Publication No.
Figure No.
Title
1386
1386--5.0
Figure 12.1
DC PWM Servo Drive (Multi-Axis)
1387B
1387-5.0
Figure 12.2
DC Spindle Drive (Analog) Product Data
1388
1388-5.1
Figure 12.3
DC PWM Servo Drive (Single Axis) Product Data Series B
1389
1389-5.1
Figure 12.5
AC Servo Amplifier (Multi--Axis) Product Data
1391
1391-5.0
Figure 12.6
AC Servo Amplifier (Single Axis) Product Data
1392
1392-5.1
Figure 12.4
High Performance AC Drive (460V and 230V) Product Data
For digital drive systems, refer to sections beginning on page 13A-1 (for
8520 systems) or page 11A-1 (for 1394 systems). For non A-B analog
drives, refer to documentation prepared by the drive manufacturer along
with the analog specifications given in this manual for your specific
processor.
The figures in this section emphasize the wiring between the termination
panel and E-STOP string to the drives. They do not show complete
detailing of the drives. You should have your drive manual handy when
you use these figures.
12.0
Section Overview
