Section

9A-1

Operator Interface

This section covers the integration of the components that make up the

Operator Interface for the 9/Series CNCs. A section is devoted to each of

the following components:

Operator Panel (Display device and keyboard -- 3 versions)
- Mounted Monochrome operator panel
- Mounted Color panel (CRT and Flat panel)
- Removable operator panel

MTB Panel

(selector switches and pushbuttons -- 3 versions)

- Standard MTB panel with fiber optic connection
- LED type Lamp panel with fiber optic connection
- LED type Lamp panel with Direct 24 V I/O connection
HPG

(Hand pulse generator for manual jogging)

These components work together to enable the machine tool operator to

interface with the control. Data entered through the operator panel

keyboard, the MTB panel push buttons and switches, and the HPG

handwheel is input to the control via the system I/O ring. How the specific

components connect and interact with other modules of the control is

explained in the following sections.

The operator can edit programs, view system data, perform machine

functions, and many other tasks through the operator panel. The operator

panel allows an interface to/from the control through:

5 softkeys and 2 page keys
a keyboard with 51 alphanumeric, control, and shift keys
the display (CRT or TFT)

The display terminal can be either a 9--inch monochrome CRT, a 12--inch

color CRT, or the 10.4 inch color flat screen TFT. The system installer

must set an AMP parameter to select between the color and monochrome

displays (the removable operator panel is always a monochrome display,

the flat panel is always configured as a color display). The color displays

will use all white characters if the AMP parameter is set incorrectly to

“monochrome”. A monochrome display will not display any RED

characters if AMP is configured for a color panel. This includes ALL of

the system emergency messages.

9A.0

Section Overview

9A.1

Operator Panel Overview
