Chapter 9B
Integrating Your Teach Pendant
9B-8
If the teach pendant does not respond, a watchdog timeout occurs and:
$TPTO is set
an error message is displayed on the operator panel CRT
PAL can control the activities in response to the timeout
system continues to send watchdog signals to try and reestablish
communication. When the system receives a correct response packet,
the control sets $TPTO to false.
A watchdog timeout can also occur if 3 ENQs are sent to the teach pendant
in response to NAKs.
Receiving Error Messages
If requested by the teach pendant with a CMD 61 (hex) and SD1=04, when
the control displays an error message, it also sends the message in ASCII
to the teach pendant:
CMD SD1 SD2 SD3 TNS TNS
DATA
DLE STX
62
02
00
00
00
04
PAL DOES NOT EXIST NULL
DLE ETX BCC
ASCII
The teach pendant does not have to respond to the message. It only has to
send an ACK or a NAK.
If you send an illegal request from the teach pendant to the control, the
control sends a message back telling you about the illegal request. In the
message from the control the SD2 and SD3 fields contain the information
that identifies the illegal request:
This Field
Contains this Information about the Illegal Request
SD2
CMD value received
SD3
SD1 value received
For example, if the teach pendant sends this illegal request:
CMD SD1 SD2 SD3 TNS TNS
DLE STX
71
02
00
00
00
41 DLE ETX BCC
The teach interface software responds with:
CMD SD1 SD2 SD3 TNS TNS
DLE STX
63
00
71
02
00
21 DLE ETX BCC
To the teach interface software, an illegal request is any request that does
not match those defined in this section.
END OF SECTION
9B.7
Receiving the Illegal
Request Message from the
CNC
(CMD=63 hex)
