Table 7a.a cable and connector list (continued) – Rockwell Automation 8520 9/Series CNC Integration Maintenance Manual Documentation Set User Manual
Page 362
Section 7A
Connecting Components
7A-14
Table 7A.A
Cable and Connector List (continued)
Cable No.
Control
From Module and
Connector
Cable Name
To Module and Connector
Cat. No.
C01
9/260 and
9/290 only
Main Power Supply BT04
ON/OFF Switch Signal Cable
MTB Panel BT20
Prepared by Customer
C01
BT20
BT04
19574
L1
ac
IN
L2
PE
H
L
AUX
ac
ON
COM
OFF
E-Stop
COM
RESET
ON
SW
COM
OFF
SW
Connector On End of Cable
Cable Type
Connector On End of Cable
Max. Cable Length
Miscellaneous
Belden 9491
Miscellaneous
Line Drop Limit
Cable No.
Control
From Module and
Connector
Cable Name
To Module and Connector
Cat. No.
C01
9/440 (all)
only
On/Off Power Control Module
ON/OFF Switch Signal Cable
MTB Panel BT20
Prepared by Customer
C01
BT20
L1
ac
IN
L2
PE
L1
L2
AUX
ac
ON
COM
OFF
E-Stop
COM
RESET
ON SW
COMMON
OFF SW
On/Off Power Control Module
Connector On End of Cable
Cable Type
Connector On End of Cable
Max. Cable Length
Miscellaneous
Belden 9491
Miscellaneous
Line Drop Limit
