Connecting the 3-axis Servo Module
4B-7
The functions of the digital servo module are designed to make the axes
run with optimum performance. Generally, the maximum feedrates are
limited by the mechanical abilities of the machine. System gain and the
maximum allowable following error will also limit the feedrates. These
limits are entered as AMP parameters. Refer to the 9/Series CNC 9/230,
9/260, and 9/290 AMP Reference Manual, publication 8520-6.4, for more
information.
Table 4C.A lists the connectors that are used to integrate the digital servo
module with other modules of the control.
Table 4B.A
Digital Servo Module Connectors
Connector on Servo Module
Connected to:
Cable Number Remark
Component
Connector
CN1
Motherboard
P4, P5 or P6
C12
CN2
Servo Amplifier
CNA1
C19
Axis 1
CN3
Servo Amplifier
CNA2
C19
Axis 2
CN4
Servo Amplifier
CNA3
C19
Axis 3
CN5
Feedback Device
C17
1
CN6
Feedback Device
C17
1
CN7
Feedback Device
C17
1
CN8
Spindle
C21
CN9
Touch Probe
C22
CN10
Battery Pack
C23
CN11
Optional Feedback Module
CN12
Optional Feedback Module
CN13
+5V Encoder Power Cable from Main Power Supply
Important:
When 1 servo module is used, it must be connected to P4 of the motherboard. When 2
servo modules are used, the first servo module must be connected to P4 and the second to connector P6.
9/290 only, when three modules are used, connect the first to P4, the second to P6 and the third to P5.
1
If a spindle incorporates an encoder to supply position feedback to the servo module, the spindle
encoder must be interfaced with the last open connector of these 3 connectors. Refer to the
9/260-9/290 AMP Reference Manual, publication 8520-6.4, for more information.
CN1 Servo Module Interface Connector
The servo module is interfaced with the motherboard through connector
CN1. The control transmits and receives various signals to and from the
servo module through this connector.
4B.2.1
Servo Module Connectors
and Pin Assignments
