Page 125

Section 3B
Power Distribution
3B-4
The input power specifications of the main power supply, the operator panel
power supply, and the portable operator panel interface module power supply
are shown in Table 4D.A and Table 4D.B. For output power specifications of
the main power supply for the 9/260 and 9/290, refer to page 4A-10. For output
power specifications of the operator panel power supply, refer to page 9A-7.
Table 3B.A
Main Input Power Specifications
Item
Specifications
Remark
Input Rated Input
115V/230V ac -- 50/60Hz
Input Range
90-265V ac -- 47-63Hz
Power Consumption
8520-PS1
8520-PS2A
225 Watts @ 50
°
C
130 Watts @ 50
°
C
168 Watts @ 60
°
C or 225 Watts
with min. 25 CFM
96.4 Watts @ 60
°
C or 130 Watts
with 25 CFM
Fuse
8A/250V
Protects power supply module
and sub-power supply and the
color CRT
Connection
Terminal Block
3B.2
Main and Operator Panel
Power Supply Input Power
Specifications
