Brocade TurboIron 24X Series Configuration Guide - Manual (Page 973)

Brocade TurboIron 24X Series Configuration Guide 939
53-1003053-01
Viewing traffic policies
Syntax: show statistics traffic-policy []
Table 144 explains the output of the show access-list accounting and show statistics traffic-policy
commands.
Clearing ACL and rate limit counters
The device keeps a running tally of the number of packets and the number of bytes per packet that
are filtered by ACL statements and rate limiting traffic policies. You can clear these accumulated
counters, essentially resetting them to zero. To do so, use either the clear access-list account
traffic-policy or the clear statistics traffic-policy command.
To clear the counters for ACL counting and rate limit counting, enter commands such as the
following.
TurboIron(config)#clear access-list accounting traffic-policy CountOne
TurboIron(config)#clear statistics traffic-policy CountTwo
Syntax: clear access-list accounting traffic-policy
or
Syntax: clear statistics traffic-policy
where is the name of the traffic policy definition for which you want to clear traffic
policy counters.
Viewing traffic policies
To view traffic policies that are currently defined on the device, enter the show traffic-policy
command. An example display output is shown below.
Table 145 defines the output.
TABLE 144 ACL and rate limit counting statistics
This line... Displays...
Traffic Policy The name of the traffic policy.
General Counters
Port Region # The port region to which the active traffic policy applies.
Byte Count The number of bytes that were filtered (matched ACL clauses).
Packet Count The number of packets that were filtered (matched ACL clauses).
Rate Limiting Counters
Port Region# The port region to which the active traffic policy applies.
Green Conformance The number of bytes that did not exceed the CIR packet rate.
Yellow Conformance The number of bytes that exceeded the CIR packet rate.
Red Conformance The number of bytes that exceeded the PIR packet rate.
