518

Brocade TurboIron 24X Series Configuration Guide

53-1003053-01

Configuring standard STP parameters

Syntax: show span [vlan ] | [pvst-mode] | [] | [detail [vlan [ethernet

] | ]]

The vlan parameter displays STP information for the specified port-based VLAN.

The pvst-mode parameter displays STP information for the device Per VLAN Spanning Tree (PVST+)
compatibility configuration. Refer to

“PVST/PVST+ compatibility”

on page 568

The > parameter is a valid port number.

The parameter displays only the entries after the number you specify. For example, on a
device with three port-based VLANs, if you enter 1, then information for the second and third VLANs
is displayed, but information for the first VLAN is not displayed. Information is displayed according
to VLAN number, in ascending order. The entry number is not the same as the VLAN number. For
example, if you have port-based VLANs 1, 10, and 2024, then the command output has three STP
entries. To display information for VLANs 10 and 2024 only, enter show span 1.

The detail parameter and its additional optional parameters display detailed information for
individual ports. Refer to

“Displaying detailed STP information for each interface”

on page 520.

The show span command shows the following information.

TABLE 88

CLI display of STP information

This field...

Displays...

Global STP parameters

VLAN ID

The port-based VLAN that contains this spanning tree (instance of STP). VLAN 1 is
the default VLAN. If you have not configured port-based VLANs on this device, all
STP information is for VLAN 1.

Root ID

The ID assigned by STP to the root bridge for this spanning tree.

TurboIron#show span

VLAN 1 BPDU cam_index is 3 and the Master DMA Are(HEX)

STP instance owned by VLAN 1

Global STP (IEEE 802.1D) Parameters:

VLAN Root Root Root Prio Max He- Ho- Fwd Last Chg Bridge

ID ID Cost Port rity Age llo ld dly Chang cnt Address

Hex sec sec sec sec sec

1 80000000004d4a00 0 Root 8000 20 2 1 15 689 1 0000004d4a00

Port STP Parameters:

Port Prio Path State Fwd Design Designated Designated

Num rity Cost Trans Cost Root Bridge

Hex

1 80 19 FORWARDING 1 0 80000000004d4a00 80000000004d4a00

2 80 0 DISABLED 0 0 0000000000000000 0000000000000000

3 80 0 DISABLED 0 0 0000000000000000 0000000000000000

4 80 0 DISABLED 0 0 0000000000000000 0000000000000000

5 80 19 FORWARDING 1 0 80000000004d4a00 80000000004d4a00

6 80 19 BLOCKING 0 0 80000000004d4a00 80000000004d4a00

7 80 0 DISABLED 0 0 0000000000000000 0000000000000000
