Brocade TurboIron 24X Series Configuration Guide

443

53-1003053-01

Basic IP parameters and defaults – Layer 3 Switches

ARP age

The amount of time the device keeps a MAC address
learned through ARP in the device ARP cache. The
device resets the timer to zero each time the ARP
entry is refreshed and removes the entry if the timer
reaches the ARP age.
NOTE: You also can change the ARP age on an

individual interface basis. Refer to

Table 71

on page 445.

Ten minutes

page 460

Proxy ARP

An IP mechanism a router can use to answer an ARP
request on behalf of a host, by replying with the
router own MAC address instead of the host.

Disabled

page 460

Static ARP
entries

An ARP entry you place in the static ARP table.
Static entries do not age out.

No entries

page 461

Time to Live
(TTL)

The maximum number of routers (hops) through
which a packet can pass before being discarded.
Each router decreases a packet TTL by 1 before
forwarding the packet. If decreasing the TTL causes
the TTL to be 0, the router drops the packet instead
of forwarding it.

64 hops

page 462

Directed
broadcast
mode

The packet format the router treats as a directed
broadcast. The following formats can be directed
broadcast:

All ones in the host portion of the packet
destination address.

All zeroes in the host portion of the packet
destination address.

All ones
NOTE: If you enable

all-zeroes
directed
broadcasts,
all-ones directed
broadcasts
remain enabled.

page 463

Source-routed
packet
forwarding

A source-routed packet contains a list of IP
addresses through which the packet must pass to
reach its destination.

Enabled

page 462

Internet Control
Message
Protocol (ICMP)
messages

The Layer 3 Switch can send the following types of
ICMP messages:

Echo messages (ping messages)

Destination Unreachable messages

Enabled

page 463

ICMP Router
Discovery
Protocol (IRDP)

An IP protocol a router can use to advertise the IP
addresses of its router interfaces to directly
attached hosts. You can enable or disable the
protocol, and change the following protocol
parameters:

Forwarding method (broadcast or multicast)

Hold time

Maximum advertisement interval

Minimum advertisement interval

Router preference level

NOTE: You also can enable or disable IRDP and

configure the parameters on an individual
interface basis. Refer to

Table 71

on

page 445.

Disabled

page 477

TABLE 70

IP global parameters – Layer 3 Switches (Continued)

Parameter

Description

Default

See page...
